• CPU Compatibility: Supports Intel® 14th/13th/12th Gen, Pentium® Gold, and Celeron® processors (LGA 1700 socket).
  • DDR5 Memory Support: Dual channel DDR5 up to 6400+MHz (OC) for high-speed performance.
  • Core & Memory Boost: Optimized power and signal design for enhanced CPU and RAM performance.
  • Fast Storage & Expansion: PCIe 4.0 and Lightning Gen4 x4 M.2 with Shield Frozr for maximum speed.
  • Advanced Networking: 2.5G LAN and Wi-Fi 6E for secure, fast, and stable connections.
  • Premium Audio & Durability: Studio-grade AUDIO BOOST and Steel Armor for enhanced sound and GPU protection.

 0 Ratings 0 Answered Questions

Brand: MSI |

Share Buttons
NPR. 23,000 Rs. 26,900 14.50%

Quantity

Delivery Options

cash on delivery / phone Pay

Home Delivery

2 to 3 Days Days

Shipping Price : NPR. 100/kg
Cash on Delivery Available
Return

within 7 days days easy return Change of mind is not applicable

2 year
CPU SUPPORT Supports 14th, 13th & 12th Gen Intel® Core™ Processors for LGA 1700 Socket
CHIPSET Intel® B760
MEMORY (RAM)

2x DDR5, Maximum Memory Capacity 128GB
Memory Support DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC)
Max. overclocking frequency:
• 1DPC 1R Max speed up to 6400+ MHz
• 1DPC 2R Max speed up to 5600+ MHz

Supports Intel® XMP 3.0 OC
Supports Dual-Controller Dual-Channel mode
Supports non-ECC, un-buffered memor

ONBOARD GRAPHICS

1x HDMI™
Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz*
1x DisplayPort
Support DP 1.4, maximum resolution of 4K 60Hz*
1x D-Sub
Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz

*Available only on processors featuring integrated graphics

EXPANSION SLOTS

1x PCI-E x16 slot (Qty)
1x PCI-E x1 slot (Qty)
PCI_E1 Gen PCIe 4.0 supports up to (From CPU)
PCI_E2 Gen PCIe 4.0 supports up to (From Chipset)

MULTI-GPU N/A
STORAGE

2x M.2 (Qty)
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
4x SATA 6G (Qty)
* SATA7 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.

RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
LAN 1x Realtek® RTL8125BG 2.5Gbps LAN
WIRELESS / BLUETOOTH Intel® Wi-Fi 6E, Supports Bluetooth® 5.3
USB 2x USB 2.0 (Back)
4x USB 2.0 (Internal)
4x USB 3.2 Gen 1 5Gbps Type-A (Back)
2x USB 3.2 Gen 1 5Gbps Type-A (Internal)
AUDIO Realtek® ALC897 Codec
7.1-Channel High Definition Audio
BACK I / O PORTS 1x DisplayPort 1.4
4x USB 3.2 Gen 1 5Gbps (Type-A)
2x USB 2.0 (Type-A)
1x 2.5G LAN
Wi-Fi / Bluetooth
Audio Connectors
1x HDMI™ 2.1
1x VGA
LED FEATURE 2x ARGB LED Connector
1x RGB LED connectors
4x EZ Debug LED
OPERATING SYSTEM Support for Windows® 11 64-bit, Windows® 10 64-bit
FORM FACTOR m-ATX
243.84mm x 220mm
